In the pharmaceutical industry, maintaining a sterile and contamination-free environment is critical. One of the primary ways this is achieved is through the use of cleanrooms—controlled environments designed to regulate airborne particles, microbial levels, and airflow dynamics. To standardize and ensure compliance with international quality norms, cleanrooms are classified into different grades. These are often aligned with ISO (International Organization for Standardization) cleanroom classifications or older systems such as Federal Standard 209E.
This article explores cleanroom grades in pharma, their classification criteria, and the operational significance of each grade.
What Are Cleanroom Grades?
Cleanroom grades are a way to categorize controlled environments based on how clean the air is. In pharma, this is vital to ensure that sterile products—like injectables, ophthalmics, and certain oral drugs—are manufactured in environments with minimal risk of contamination from particles or microorganisms.
Each grade corresponds to a maximum allowable limit of airborne particles of certain sizes, with specific requirements for air changes per hour, type of airflow, and pressure differentials.
Key Cleanroom Grades and Their Significance
1. Grade A – The Sterile Core (ISO Class 5)
- Particle Count: ≤ 3,520 particles/m³ ≥ 0.5 µm
- Larger Particles (≥5.0 µm): 0 particles allowed
- Air Changes: ≥ 60–40 changes/hour (CH)
- Airflow Type: Unidirectional (Laminar Flow)
- Filtration: 99.99% at 0.3 µm through HEPA filters
Use Case:
Grade A is used for high-risk operations such as aseptic filling, open vial handling, and sterile compounding. It ensures the highest level of cleanliness and is typically maintained using laminar airflow cabinets or isolators.
2. Grade B – Clean Support Area (ISO Class 7 at rest, ISO 5 operational)
- Particle Count at Rest: ≤ 352,000 particles/m³ ≥ 0.5 µm
- Operational Particle Count: ≤ 3,520 particles/m³ ≥ 0.5 µm
- Air Changes: Mixed or directional, with ≥10–15 Pa differential pressure
Use Case:
Grade B is the background environment for Grade A zones. It supports aseptic operations and provides clean conditions for gowning areas, preparation rooms, and sterile support functions.
ALSO READ: Clean Room Validation Requirements
3. Grade C – Controlled but Moderate (ISO Class 7)
- Particle Count at Rest: ≤ 352,000 particles/m³ ≥ 0.5 µm
- Operational Particle Count: ≤ 3,520,000 particles/m³ ≥ 0.5 µm
- Air Changes: 20–40 ACPH (Air Changes Per Hour)
- Airflow: Turbulent
- Filtration: HEPA
Use Case:
Grade C cleanrooms are used for less critical stages of sterile manufacturing, such as solution preparation before sterilization, formulation of non-sterile products, or handling of semi-processed APIs.
4. Grade D – Basic Controlled Area (ISO Class 8)
- Particle Count at Rest: ≤ 3,520,000 particles/m³ ≥ 0.5 µm
- Operational Limit: No defined particle limit
- Air Changes: 10–20 ACPH
- Filtration: HEPA
Use Case:
Grade D is typically suitable for general pharmaceutical manufacturing tasks such as dispensing of raw materials, packaging, and less sensitive processes.
ISO Cleanroom Classifications Overview
|
ISO Class |
Maximum Particles ≥ 0.5 µm/m³ |
Federal Standard 209E Equivalent |
|
ISO 5 |
≤ 3,520 |
Class 100 |
|
ISO 6 |
≤ 35,200 |
Class 1,000 |
|
ISO 7 |
≤ 352,000 |
Class 10,000 |
|
ISO 8 |
≤ 3,520,000 |
Class
100,000 |
These classifications provide a standardized benchmark for cleanroom performance globally, ensuring cross-border compliance and quality assurance in pharmaceutical manufacturing.
Why Cleanroom Grades Matter in Pharmaceutical?
Maintaining correct cleanroom grades is not just about regulatory compliance—it's about patient safety and product efficacy. Here's why it’s critical:
- Minimizes contamination risk during aseptic manufacturing
- Ensures regulatory approval by bodies like the FDA, EMA, or WHO
- Protects product integrity during critical processing steps
- Supports GMP compliance and builds trust with clients and patients
Airflow, Pressure, and Filtration—Key Supporting Elements
- Unidirectional (laminar) flow is crucial in Grade A areas to ensure particles are swept away from sterile zones.
- Turbulent airflow in Grade C and D areas mixes air to reduce the concentration of particles.
- Pressure differentials ensure that air moves from cleaner to less clean areas, preventing back-contamination.
- HEPA filters are standard in all grades, providing >99.97% efficiency in removing particles ≥0.3 µm.
Understanding and implementing cleanroom grades in pharmaceutical manufacturing is essential for ensuring the sterility and safety of drug products. Whether you're working in sterile injectables, biotech, or traditional formulations, adhering to cleanroom standards ensures your operations are compliant, safe, and high-quality.
In summary, cleanroom classification is not merely a technical requirement—it’s a foundational aspect of modern pharmaceutical manufacturing. It protects patients, products, and your business reputation.
